Sold
Type of machine : CNC machining centre
Brand : WILLEMIN MACODEL
N° de stock: 90068
Model : W408 BV
Year : 2004
Location : 73240 Saint-Genix-les-Villages, FRANCE
MACHINE SOLD
Interested in a similar model?
Leave us your contact details:
Technical characteristics
CNC control
FANUC 16i-MB
Number of axes
5
Stroke X axis
250 [mm]
Stroke Y axis
200 [mm]
Stroke Z axis
300 [mm]
Feed rate on X, Y and Z axes
30000 [mm/min]
Angular C axis stroke
360 [°]
B axis swivelling stroke
-10° / +115° [°]
B axis indexing precision
0.001 [°]
Spindle type
HSK E40
Min. spindle speed
500 [rpm]
Max. spindle speed
30000 [rpm]
Tool changer magazin number of stations
24
RS232 Interface
Yes
Centralized lubrication
2.7 [l]
Rated current
25 [A]
Supply voltage
400 [V]
Number of hours under power
5430 [h]
Spindle running hours
1435 [h]
Dimensions
1800 x 1500 x 2430 [mm]
Weight
1700 [Kg]
Additional information
EQUIPEMENT INCLUDED:
x3 HEIDENHAIN glass scales on all 3 axes (X, Y and Z)
x1 liquid coolant spindle unit
x1 tool breakage detection device
x1 oil mist extraction unit
x1 chip tray
x1 coolant pump
x1 complete users manual in French
